Visually inspect your enterprise assets and resources via your browser from anywhere in the world
The AKCP Pan Tilt Dome Digital Camera is designed to provide greater functionality to the securityProbe range of devices.
The AKCP Pan Tilt Dome Digital Camera is designed to provide greater functionality to the securityProbe range of devices. Not only can you monitor assets and infrastructure remotely, combining the AKCP PTDC Camera with a securityProbe allows you to actually see any problems, from anywhere in the world.
The AKCP PTDC is designed around a high resolution CCD camera from Sony. The pictures are truly stunning even in low light conditions. The camera features AWB (Auto White Balance), and has a horizontal resolution of 640 pixels per line, with 625 lines (interlaced). The sensor is a 1/3″ interline CCD. It has excellent low light sensitivity of 0.5 lux at f1.2.
The SC1 comes in 2 versions: PAL and NTSC, to conform to regional Video Broadcast Standards. Multiple cameras on one system must be of the same type, PAL or NTSC.
Live full-color streaming video is available at up to 30fps via the web interface, and up to 50 streams of video can be accessed simultaneously. Standard JPG format pictures are used, allowing the use of third party host tools to store and analyze the JPG pictures. All pictures are in the Standard JPG format and the Standard CIF picture size is 352 x 288 pixels or VGA (640 x 480). The pictures can be easily downloaded from the securityProbe into a local host.
Monitor environments remotely and record events
Specifications
| Image Sensor for Universal Mount Camera (UMC) |
| High quality Sony CCD |
| Light sensitivity of .5 lux at f1.2 |
| 1/3″ interline CCD |
| Auto White Balance |
| 640 pixels per line, with 625 per frame (interlaced) |
| Electronic Iris: 1/50 – 1/100,000 (PAL); 1/60 – 1/100,000 (NTSC) |
| Picture Elements: 640 (H) x 480 (V) |
| S/N ratio: 45 dB or more (AGC off) |
| Connections |
| Video: BNC Male video composite out 1 Vp-p 75 ohm |
| Power: 2.5 mm Male plug |
| Optics |
| Lens type: fixed |
| Focal Length: 3.6 mm |
| Physical and Environmental |
| Dimensions: (Ø x H): 10.7 x 11.5 cm |
| Weight: 0.8 kg |
| Power: 9 V DC, external |
| Power consumption: 2.16 W |
| Operating temp. range: 0 – 40 °C |
| Operating humidity range: 10 – 80 % RH, non-condensing |
4 Built-in Pan and Tilt Controllers
The SC1 has 4 built-in pan and tilt controllers to control the high precision stepper motors in the Pan Tilt Dome Digital Camera, which can pan the camera left to right and up or down. This allows the Administrator to adjust the viewing angle of the camera over the network via the web interface. Administrator level access gives you control of the brightness and contrast of the image.
Whether you are connecting the High Definition Pan Tilt Dome Camera to a securityProbe 5ESV or a AKCP Door Control Unit. The connection type and port number is Universal.
Four video ports on the rear of each unit are assigned to High Definition Digital Camera connectivity.
